User adjustable ON Time and OFF Time ON time range: 1 to 90 Minutes OFF time range: 1 to 90 Minutes OFF to ON jump switch Motor Running Indication
This product is a timer that will
periodically turn ON and OFF your Single Phase Monoblock pump based on the
timings adjusted by the user. The ON time or the running time is the total time
for which the motor is supposed to turn ON in a cycle. The OFF time or the
waiting time is the total time for which the motor should wait. The OFF time is
also the recharge time if the water level in the borewell is low. The task of
the cyclic timer is to turn ON the motor for the set ON duration and keep the
motor in the OFF state for the set OFF time. After the set OFF time is up, the
motor will again be switched to the ON cycle and so on.
Connections:
Connect the first set of Red and Black wires to
incoming Single Phase (220V AC) power supply Connect the second set of Red and
Black wires to motor cables/ to your motor starter (MCB type)
Operation:
The timer
display powers up as soon as the power supply is ON. The timer displays the set
ON time and OFF time for 5 seconds during power ON. The ON time is displayed in
green and the OFF time is displayed in red. The timer will resume its operation
from where it had previously stopped. The blinking of the LED determines the
current cycle the timer is in. The numbers against the blinking digit indicate
the elapsed time. For the whole time, the timer is in a particular cycle, the
other cycle will display the set time. The timer hence shuffles between the ON
and OFF cycles one after the other.
Technical Specifications:
Minimum
operating Voltage 150V Maximum operating voltage 250V
Setting:
Setting ON time:
ON time is displayed in green Press the button on the right hand
side You will notice the green digits
numbers increasing Keep pressing if you want to
increase the ON time If you want to decrease the ON time,
release the button on the right and immediately press the button on the left Arrive at the required time Wait for the blink of all the digits
for saving the set times
Setting OFF time:
OFF time is
displayed in red. Press the button on the left hand
side You will notice the red digits
numbers increasing Keep pressing if you want to
increase the OFF time If you want to decrease the OFF
time, release the button on the left and immediately press the button on the
right Arrive at the required time Wait for the blink of all the digits
for saving the set times To verify of the desired times are
set, power OFF the timer and power it back ON and notice the saved time for 5
seconds
Applications:
In conditions where the availability of water in
the bore well is low In conditions where
there is excess water and it is sufficient if the motor is run only for a
specific time Hydroponics Commercial Complexe Horticulture
